Hikvision iDS-7104HQHI-M1/T 4 CH 1080P Mini 1U H.265 AcuSense DVR, HD TVI & Analog Camara
| Login to See Price | |
| Product Model: | iDS-7104HQHI-M1/T |
| Brand: | HIKVISION |
Key Features
- Model: IDS-7104HQHI-M1/T
- H.265 Pro+/H.265 Pro/H.265 video compression
- HDTVI/AHD/CVI/CVBS/IP video inputs
- Up to 6-ch IP camera inputs (up to 6 MP)
- Up to 1080p@15 fps encoding capability
Brand: HIKVISION
Product Model: iDS-7104HQHI-M1/T
Return & Warranty
Market Ratings
Ship On Time
99%
Chat Response
100%
Specification
| Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 | |
| Resolution | When 1080p Lite mode is not enabled: 3K lite/5 MP lite/4 MP lite/1080p/720p/VGA/WD1/4CIF/CIF; When 1080p Lite mode is enabled: 3K lite/5 MP lite/4 MP lite/1080p lite/720p lite/VGA/WD1/4CIF/CIF | |
| Bit Rate | 32 Kbps to 6 Mbps | |
| Others | Frame Rate Main stream: When 1080p Lite mode not enabled: For 3K stream access: 3K lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps For 5 MP stream access: 5 MP lite@12fps;4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@20fps For 4 MP stream access: 4 MP lite/1080p@15fps;720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) When 1080p Lite mode enabled: 3K lite/5 MP lite@12fps;4 MP lite@15fps;1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) Sub-stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) Video Bitrate 32 Kbps to 6 Mbps Stream Type Video, Video & Audio Audio Compression G.711u Audio Bitrate 64 Kbps |
|
| Video Detection And Alarm | ||
| Alarm Input | N/A | |
| Network | ||
| Ethernet Port | 1, RJ45 10/100 Mbps self-adaptive Ethernet interface | |
| Network Function | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF | |
| Storage | ||
| Internal HDD | 1 SATA interface | |
| Auxiliary Interface | ||
| USB | Rear panel: 2 × USB 2.0 | |
| Power | ||
| Power Supply | 12VDC, 1.33A | |
| Power Consumption | ≤ 8 W (without HDD) | |
| Construction | ||
| Dimensions | 200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch) | |
| Net Weight | ≤ 1 kg (without HDD, 2.2 lb.) | |
| Warranty | ||
| Manufacturing Warranty | 01-Year Warranty | |
