Hikvision DS-D5024F2-BP2 Monitor, 23.8 Inch, FHD 1920x1080, IPS, E-LED, VGA & HDMI, 100Hz, 3YW, Black
| Login to See Price | |
| Product Model: | DS-D5024F2-BP2 |
| Brand: | HIKVISION |
Key Features
| Model: Hikvision DS-D5024F2-BP2 |
| Display Size: 23.8 inch |
| Resulation: FHD (1920 x 1080) |
| Ports: VGA×1, HDMI×1 |
| Features: Low Blue Light, VESA wall mount |
Brand: HIKVISION
Product Model: DS-D5024F2-BP2
Return & Warranty
Market Ratings
Ship On Time
99%
Chat Response
100%
Specification
| Code Name | DS-D5024F2-BP2 |
| Display | |
| Screen Size | 23.8 inch |
| Active Display Area | 527.04 (H) mm × 296.46 (V) mm |
| Resolution | 1920 × 1080 |
| Backlight | E-LED |
| Pixel Pitch | 0.2745 (H) mm × 0.2745 (V) mm |
| Brightness | 250 cd/m² |
| Viewing Angle | 178° (H)/178° (V) |
| Color Depth | 16.78 M |
| Contrast Ratio | 1000:1 |
| Response Time | 14 ms |
| Refresh Rate | Typ. 60 Hz, Max. 100 Hz |
| Haze | Haze 25%, 3H |
| Reliability | 7 × 16 H |
| Color Gamut | 72% NTSC |
| Interface | |
| Video & Audio Input | HDMI 1.4 × 1, VGA × 1 |
| Video & Audio Output | Audio Out × 1 |
| Power | |
| Power Supply | DC 12 V, 2.0 A |
| Power Consumption | ≤ 24 W |
| Standby Consumption | ≤ 0.5 W |
| Working Environment | |
| Working Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
| Working Humidity | 20% RH to 90% RH (Non-Condensing) |
| Storage Temperature | -20 °C to 60 °C (-4 °F to 140 °F) |
| Storage Humidity | 10% RH to 90% RH (Non-Condensing) |
| General | |
| VESA | 75 mm × 75 mm (4 - M4 × 6 mm) |
| Bezel Width | 2.0 mm (top/left/right), 23.55 mm (bottom) |
| Product Dimensions (W × H × D) | With base: 539.7 (W) mm × 399.9 (H) mm × 164.72(D) mm 21.25 (W) inch × 15.74 (H) inch × 6.49 (D) inch Without base: 539.7 (W) mm × 327.33 (H) mm × 43.5 (D) mm 21.25 (W) inch × 12.89 (H) inch × 1.71 (D) inch |
| Package Dimensions (W × H × D) | 652 (W) mm × 445 (H) mm × 116 (D) mm 25.67 (W) inch × 17.52 (H) inch × 4.57 (D) inch |
| Net Weight | 2.32 ± 0.5 kg (5.11 ± 1.10 lb) |
| Gross Weight | 3.74± 0.5 kg (8.25 ± 1.10 lb) |
| Packing List | Monitor × 1, Base component × 1, Power adapter (12 V, 2 A) × 1, HDMI cable (1.5 m) × 1, User manual × 1, Multilingual manual × 1 |
| Remarks | The base is included by default. The product appearance and parameters in this specification may vary from your actual device. Please consult our local sales staff for further information |
| Interface | |
| HDMI | HDMI 1.4 digital signal input interface |
| Audio Out | 3.5 mm Audio output interface |
| Interface | |
| VGA | VGA analog signal input interface |
| DC | DC 12 V 2.0 A input interface |
| Warrenty | 3 year |
