GIGABYTE INTEL® # Z790M AORUS ELITE AX DDR5, LGA1700, 4 x DDR5 DIMM, 6 x SATA 6Gb/s

5.0
0 reviews
Write a review
Login to See Price
Product Model: GIGABYTE INTEL® # Z790M AORUS ELITE AX DDR5
Brand: GIGABYTE

Key Features

  • Model: Z790 AORUS ELITE AX
  • Supported CPU: 14th Gen, 13th Gen & 12th Gen Processors (LGA1700)
  • Supported RAM: 4 x DDR5 DIMMs, up to 7600(O.C.)
  • Graphics Output: 1 x HDMI, 1 x DisplayPort
  • Features: 2.5GbE LAN & Wi-Fi 6E 802.11ax
  • View More Info

    • Brand: GIGABYTE
    Product Model: GIGABYTE INTEL® # Z790M AORUS ELITE AX DDR5
    -
    +
    Delivery Options
    Within Bangladesh
    CHANGE
    Standard Delivery
    Get within 3 days
    120৳
    Cash on Delivery
    Return & Warranty
    Authentic
    Easy Return
    Warranty Services
    Market Ratings
    99%
    Ship On Time
    99%
    Chat Response
    100%
    Place Order
    • Specification
    • Description
    • Reviews (0)
    • Tags
    Specification
    • CPU:
      1. LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors
      2. L3 cache varies with CPU
    • Chipset: Intel® Z790 Express Chipset
    • Memory:
      1. Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 memory modules
      2. 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory
      3. Dual channel memory architecture
      4. Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
      5. Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
      6. Support for Extreme Memory Profile (XMP) memory modules
    • Onboard Graphics:
      Integrated Graphics Processor-Intel® HD Graphics support:
      1. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
        * Support for HDMI 2.1 version and HDCP 2.3.
        ** Support native HDMI 2.1 TMDS compatible ports.
      2. 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60
        * Support for DisplayPort 1.2 version and HDCP 2.3
    • Audio:
      1. Realtek® ALC1200 CODEC
      2. High Definition Audio
      3. 2/4/5.1/7.1-channel
      4. Support for S/PDIF Out
    • LAN: Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
    • Wireless Communication module:
      Intel® Wi-Fi 6E AX211
      1. WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
      2. BLUETOOTH 5.3
      3. Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate
        * Actual data rate may vary depending on environment and equipment.
    • Expansion Slots:
      CPU:
      1. 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)
        * The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.
      Chipset:
      1. 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)
      Support for AMD CrossFire™ technology
    • Storage Interface:
      CPU:
      1. 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
      Chipset:
      1. 1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB)
      2. 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
      3. 6 x SATA 6Gb/s connectors
      RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices
      RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
    • USB:
      Chipset:
      1. 1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2x2 support
      2. 1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
      3. 1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
      Chipset+2 USB 2.0 Hubs:
      1. 6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
      Chipset+2 USB 2.0 Hubs:
      1. 8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)
    • Internal I/O Connectors:
      1. 1 x 24-pin ATX main power connector
      2. 1 x 8-pin ATX 12V power connector
      3. 1 x 4-pin ATX 12V power connector
      4. 1 x CPU fan header
      5. 1 x water cooling CPU fan header
      6. 3 x system fan headers
      7. 1 x system fan/water cooling pump header
      8. 2 x addressable LED strip headers
      9. 2 x RGB LED strip headers
      10. 3 x M.2 Socket 3 connectors
      11. 6 x SATA 6Gb/s connectors
      12. 1 x front panel header
      13. 1 x front panel audio header
      14. 1 x USB Type-C® header, with USB 3.2 Gen 2 support
      15. 1 x USB 3.2 Gen 1 header
      16. 2 x USB 2.0/1.1 headers
      17. 2 x Thunderbolt™ add-in card connectors
      18. 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
      19. 1 x serial port header
      20. 1 x reset button
      21. 1 x Q-Flash Plus button
      22. 1 x Clear CMOS button
      23. 1 x reset jumper
    • Back Panel Connectors:
      1. 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
      2. 1 x USB 3.2 Gen 2 Type-A port (red)
      3. 4 x USB 3.2 Gen 1 ports
      4. 4 x USB 2.0/1.1 ports
      5. 2 x SMA antenna connectors (2T2R)
      6. 1 x HDMI 2.0 port
      7. 1 x DisplayPort
      8. 1 x RJ-45 port
      9. 1 x optical S/PDIF Out connector
      10. 2 x audio jacks
    • I/O Controller: iTE® I/O Controller Chip
    • H/W Monitoring:
      1. Voltage detection
      2. Temperature detection
      3. Fan speed detection
      4. Water cooling flow rate detection
      5. Fan fail warning
      6. Fan speed control
    • BIOS:
      1. 1 x 256 Mbit flash
      2. Use of licensed AMI UEFI BIOS
      3. PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
    • Unique Features:
      1. Support for GIGABYTE Control Center (GCC)
      2. Support for Q-Flash
      3. Support for Q-Flash Plus
      4. Support for Smart Backup
    • Bundled Software:
      1. Norton® Internet Security (OEM version)
      2. LAN bandwidth management software
    • Operating System:
      1. Support for Windows 11 64-bit
      2. Support for Windows 10 64-bit
    • Form Factor: Micro ATX Form Factor; 24.4cm x 24.4cm
    Description

    None

    Images & Videos

    None
