C11CK10401, EPSON SC-T7630D (44 Inch) Large Format Printer, 1YW
| Login to See Price | |
| Product Model: | SC-T7630D |
| Brand: | EPSON |
Key Features
• Outstanding print speeds for CAD documents of up to 16s (A1 prints) and 28s (A0 prints).
• Improved image quality with 6 colour DYE inks.
• Ultra-high capacity 1600ml ink pack for high production users
• Enhanced security with self-encrypting SSD and print authentication
• Full frontal operation with sleek chassis design
• Dual roll for increased non-stop productivity
|
Item |
Product Description |
|
Brand |
EPSON |
|
Model |
SC-T7630D |
|
Country of Origin |
Japan |
|
Country of Manufacture |
Indonesia/Vietnam/China/Philippine/Thailand |
|
Printer Width |
44 inch |
|
Printing Technology : |
|
|
Print Technology |
Inkjet |
|
Ink Type |
Dye Ink |
|
Print Head |
PrecisionCore MicroTFP Printhead |
|
Nozzle Configuration |
9600 nozzles (400 nozzles x 24 channels x 1 head) |
|
Maximum Resolution |
2400 x 1200 dpi |
|
Minimum Ink Droplet Size |
3.5 pl |
|
Line Accuracy |
±0.1% or ±0.26 mm |
|
Minimum Line Width |
0.08mm*1 (0.02mm*2) |
|
Print Speed: |
|
|
CAD A1 Landscape |
: Plain Paper 300x600dpi Line Draw/Draft: 16s, 600x600dpi Line Draw/Speed: 23s |
|
CAD A0 |
CAD A0: Plain Paper 300x600dpi Line Draw/Draft: 28s, 600x600dpi Line Draw/Speed: 43s |
|
Poster B0: |
Plain Paper 300x600dpi Epson Vivid/Speed: 46s B0: Plain Paper: 35s (Draft), 46s (Speed), 258s (High Quality), Premium Glossy Photo Paper 170gsm: 152s (Speed), 281s (Quality), 614s (Max Quality) |
|
Operators |
Operators can easily check printer status on the 4.3” LCD touch screen, and print directly from USB storage devices |
|
Ink System: |
|
|
Ink Type |
Ultra-high capacity 1600ml ink pack for high production users |
|
Colors |
Black, Cyan, Magenta, Yellow, Light Cyan, Light Magenta (6 colour 3.2 little each pouch) |
|
Paper Handling: |
|
|
Maximum Roll Diameter/Weight |
Dual-roll capability, Single Sheet, Front or Rear Loading up to 1118mm (44") wide |
|
Paper Width |
Up to 1118 mm (44") |
|
Interface |
USB + LAN + WiFi |
|
Delivering prints with improved accuracy |
Delivering prints with improved accuracy for transparent and overprint layers, as well as faster processing time for PDF and PS output. This includes additional support for printing of EPS, PDF, PS, TIFF, JPEG and Cals-G4 data. |
|
Memory |
4 GB |
|
Operating Systems |
Mac OS X 10.6.8 or later, macOS 11 or later Windows® 10, Windows® 8.1, Windows® 8, Windows® 7, Windows® Vista, Windows® XP(32bit/64bit), Windows® Server 2019/2016/2012 R2/2012/2008 R2/2008/2003 R2/2003 SP2 or later |
|
Epson Smart Panel |
Print directly from mobile devices with the Epson Smart Panel app. Transform your iOS® and Android™ mobile devices into an intuitive control centre. Conveniently set up, monitor, print, and scan on Epson printers. With a variety of configuration features, you can customise the app into an all-in-one management tool to support your needs. |
|
Supply Voltage |
240 V; 50-60Hz; 3.4A |
|
Power Consumption |
Operating: Approx. 70W / Ready: Approx. 32W / Sleep: Approx. 2.0W Standby: Approx. 0.3W |
|
Dimensions |
1,848 x 829 x 975mm (W x D x H) |
|
Weight |
Approx. 165kg |
|
What’s In the Box |
Printer, AC power cable, Setup guide, Software CD-ROM |
|
Warranty |
One Year
|
